AA8176/8030

Aluminum alloy wire AA8176/8030

Classification:

Aluminum (alloy) wires

Description:

Aluminum alloy wire AA8176/8030

Technical Data:

Size Range: 0.20mm, 0.24mm, 0.30mm, 0.40mm, 0.50mm, 9.5mm
Aluminum Content (by weight): 99.5%, 99.7%
Packing Drum size: DIN130, DIN160, DIN180, DIN250, DIN400,

Code:

V90HT-EAF

Standards:

ASTM B 800 – 05

Application:

Telecommunications wires and cables
Electric utilities like transmission lines, buried counterpoise wire
Data cables and flexible cables
Drop wire and magnet wire

Technical Parameters

Type	AA8176/8030
Size	9.5mm/12mm ±0.5mm
Parameters	Tensile strength		Elongation		Electrical resistivity (20℃）
	117--123Mpa		≥15 %		≤28.44 nΩ.m
Chemical components	Si(%)	Fe(%)	Cu(%)	Mg(%)	Zn(%)	P(%)
	0.100	0.300~0.800	0.150~0.300	0.050	0.050	0.001~0.004
	Other elements, a single max (%)		Other elements, maximum total (%)		Al least value (%)
	0.030		0.100		Remain
Production equipment	Italy Continuus - Properzi
Weight	2000Kg--2500kg
Standard	GB/T30552-2014<<Aluminum alloy wires for conductors of insulated cables>>
	GB/T3954-2014<<electrician round aluminum rod>>
	ASTM800-05<<8000 Series Aluminum Alloy Wire for Electrical Purposes— Annealed and Intermediate Tempers>>
